Key Features
Compatible with the APRS communication protocol, which allows real-time two-way data transmission by using packet communications. The NEW added stand-alone digipeater function enables the TH-D75E to operate as a temporary digipeater station in the fields, allowing APRS coverage to be expanded even in mountainous locations. |
Compatible with D-STAR amateur radio communications network, developed by the Japan Amateur Radio League (JARL). New is the simultaneous reception of 2 D-STAR signals (one on BAND A, one on Band B). |
NEW - Reflector Terminal mode for more convenient communications via D-STAR reflectors. |
Wideband and multimode reception. |
IF filters for reduced reception interference. |
IF output mode. |
Enhanced voice guidance. |
KENWOOD sound quality. |
NEW - USB Type-C port. |
Supplied With
Antenna | Yes, , Ferrite Bar Antenna suitable for receiving mid- and low-HF bands |
Battery | Yes, , KNB-75LA - Li-ion battery (1820 mAh) |
Belt Clip | Yes |
Charger | Yes, , supplied with UK (3-pin) for T-type and EU (2-pin) for E-type. |
Instruction Manual | Yes, , Printed "Basic operations" manual in English, German, French, Italian, Spanish & Dutch |
Screw Set | Yes, , for belt clip |
Amateur Radio General Features
1750 Hz Tone Burst Function. | Yes |
8.33KHz spacing on Air Band | Yes |
Alphanumeric LCD Display | Yes |
Antenna Socket | SMA |
APRS Function (via built-in TNC) | Yes |
Auto Power Off | Yes |
Automatic Repeater Offset (VHF) | Yes |
Built-in Packet TNC 1200/9600 bps | Yes, , KISS TNC |
Built-in GPS | Yes |
Built-in microSD/SDHC | Yes |
Built-in USB Type-C | Yes, , USB Serial, USB Audio Output, Mass Storage |
Built-in Bluetooth | Yes, , HSP, SPP |
Clock | Yes, , Time/Date Function |
CTCSS Encoder/Decoder | Yes, , Choice of 50 tones |
CW Band Width | Yes |
CW Pitch Frequency | Yes |
CW Reverse | Yes |
D-STAR | Yes |
DCS Encoder/Decoder | Yes, , Choice of 104 digital tones |
Detect Signal Output | Yes |
Direct Frequency Entry | Yes |
DTMF Memory | Yes, , 10 channels, 16 digits |
Dual Receive | Yes, , VHFxUHF, VHFxVHF or UHFxUHF |
ECHOLINK Memory Dialer Channels | Yes |
Firmware Upgradeable via USB Port | Yes |
FM Radio | Yes |
Front Panel KeyPad | Yes |
High-Quality Front Speaker | Yes |
IF 12 kHz Output | Yes, , to USB Audio |
Key Beep On/Off | Yes |
Key Lock | Yes |
LCD Background Color | Yes, , B/W |
Memory Channel Lock-out | Yes |
Memory Channels with Alpha-tagging | 1000 Memory Channels |
Memory Shift Function | Yes |
Menu System for individual set-up | Yes |
Meter Type | Yes, , 3 types |
Monitor Function | Yes |
Multiple Scan Functions | Yes |
Multi-scroll Key | Yes |
Packet Operation - AX25 and KISS Mode | Yes, , KISS mode only |
PC Programmable Memories | Yes |
PC Radio Control Program (Option) | Yes |
Power-On Message | Yes |
Programmable Function Keys | Yes, , 2 keys (PF1, PF2) |
QSO Log | Yes |
RX Audio Equalizer | Yes, , 5 bands |
Selectable Repeater Offsets | Yes |
Separate Squelch for A and B Bands | Yes |
SSB/CW/AM Reception | Yes |
SSB Hi-cut Filter | Yes |
AM Hi-cut Filter | Yes |
Simultaneous 2 frequency RX | Yes |
Time-Out Timer | Yes |
TX Audio Equalizer | Yes, , 4 bands |
TX/RX Audio Recording | Yes, , microSD/SDHC |
VOX | Yes |
Voice Message Memory | Yes |
Voice Guidance | Yes, (Selectable 4 speeds) |
Wide/Narrow Deviation Selection | Yes |
Wide Band Reception | Yes |
Amateur Portable Specification
RF Output Power (approx.) - High | 5 W |
RF Output Power (approx.) - Mid | 2 W |
RF Output Power (approx.) - Low | 0.5 W |
RF Output Power (approx.) - E. Low | 0.05 W |
Frequency Range - TX - VHF | 144 - 146 MHz |
Frequency Range - TX - UHF | 430 - 440 MHz |
Frequency Range - TX | 144 - 146 MHz, 430 - 440 MHz |
Frequency Range - Band A | 136 - 174 MHz, 216 - 260 MHz, 410 - 470 MHz |
Frequency Range - Band B | 0.1 - 76 MHz / 108 - 524 MHz |
Frequency Range - Band B - FM - W | 76 - 108 MHz |
Number of Channels | Total 1000 Channels |
Mode | TX: F3E, F2D, F1D, F7W RX: F3E, F2D, F1D, F7W, J3E, A3E, A1A |
Mode - Band A | F3E, F1D, F2D, F7W |
Mode - Band B | F3E, F2D, F1D, F7W, A1A, A3E, J3E, F7W |
Frequency Stability | +/- 2.0 ppm |
13.8 V DC-In Facility | Yes, (use PG-2W or PG-3J) |
Antenna Impedance - 50 Ohm | Yes |
Microphone Impedance | 2 kOhm |
Operating Temperature Range | -10 °C to +50 °C with standard battery |
Operating Voltage | DC-IN: DC 11.0 - 15.9 V (STD: DC 13.8 V) BATT: DC 6.0 - 9.6 V (STD: DC 7.4 V) |
Receiver Circuitry | F3E, F2D, F1D, F7W: Double Super Heterodyne J3E, A3E, A1A: Triple Super Heterodyne |
Receiver Intermediate Frequency - Band-A - 1st IF | 57.15 MHz |
Receiver Intermediate Frequency - Band-A - 2nd IF | 450 kHz |
Receiver Intermediate Frequency - Band-B - 1st IF | 58.05 MHz |
Receiver Intermediate Frequency - Band-B - 2nd IF | 450 kHz |
Receiver Intermediate Frequency - Band-B - 3rd IF | J3E, A3E, A1A: 10.8 kHz |
Receiver Sensitivity - A & B Bands | Amateur Band FM 12 dB SINAD FM / NFM 144 MHz Band-A: 0.18 / 0.22 uV FM / NFM 144 MHz Band-B: 0.19 / 0.24 uV FM / NFM 430 MHz Band-A: 0.18 / 0.22 uV FM / NFM 430 MHz Band-A: 0.20 / 0.25 uV DV PN9 / GMSK 4.8 kbps, BER 1% 144 MHz Band-A: 0.20 uV / 0.22 uV DV PN9 / GMSK 4.8 kbps, BER 1% 430 MHz Band-B: 0.22 uV / 0.24 uV SSB 10 dB S/N Band-A: 0.16 uV AM 10 dB S/N Band-B: 0.50 uV |
Receiver Squelch | Band-A: 0.18 uV Band-B: 0.25uV |
Receiver Spurious Rejection | 144 MHz - Band-A: 50 dB or more 430 MHZ - Band-A: 50 dB or more 144 MHz - Band-B: 45 dB or more 430 MHz - Band-B: 40 dB or more |
Receiver IF Rejection | Band-A: 60 dB or more Band-B: 55 dB or more |
Receiver Channel Selectivity | -6 dB: 12 kHz or more -50 dB: 30 kHz or less |
Receiver Audio Output | 7.4 V, 10% Dist. 400 mW or more / 8 Ohm |
Transmitter Maximum Frequency Deviation | FM: +/- 5.0 kHz |
Transmitter Modulation | FM: Reactance Modulation DV: GMSK Reactance Modulation |
Transmitter Modulation Deviation | FM: +/- 5.0 kHz NFM: +/- 2.5 kHz |
Transmitter Spurious Emissions | HI / MID: -60 dBc or less L: -50 dBc or less EL: -40 dBc or less |
Dimensions | W x H x D with KNB-75L: 56.0 x 121.95 x 32.5 mm - Projections not included - |
Weight (with battery) | with KNB-75L: 340 g (net) |
APRS Features
Alert on Special Call | Yes |
APRS Data Output | Yes, , to a PC via the USB Port or Bluetooth |
Auto Message Reply | Yes |
Decay Algorithm | Yes |
Digipeat Function | Yes |
Message Memory | Yes, , 100 Messages |
New-N Paradigm | Yes |
Packet Data Output | Yes, Yes, to a PC via the USB Port or Bluetooth |
Proportional Pathing | Yes |
QSY Function | Yes |
Received Packet Data Pop-ups | Yes |
Relay Path Display | Yes |
SmartBeaconing ™ | Yes |
State/Section /Region Pathing | Yes |
Station List Memory | Yes, , lists up to 100 Stations, with filtering and sorting options |
TX Object, Item Packet | Yes |
User Phrases | Yes |
Visible Message Notifications | Yes |
D-STAR Features
DV Mode | Yes |
DV Fast Mode | Yes, , USB Interface or Bluetooth |
DR Mode | Yes |
Communication Mode | Yes |
Communication Mode - Direct | Yes |
Communication Mode - Single Repeater | Yes |
Communication Mode - Zone | Yes |
Communication Mode - Gateway | Yes |
Communication Mode - Refrector | Yes |
Repeater List, Import/Export | Yes |
Repeater Information | Yes |
Callsign List, Import/Export | Yes |
Near Repeater Stattion Select/Scan | Yes |
Access Repeater Select | Yes |
Gateway Route Select | Yes |
Select TO Station | Yes |
TX Message | Yes |
GPS TX Mode | Yes |
GPS Sentense TX Select | Yes |
GPS Auto TX for Target Station | Yes |
Detect FM on DV Mode | Yes |
RX Popup Message | Yes |
Direct Reply | Yes |
Standby Beep | Yes |
Code SQ | Yes |
Auto Reply | Yes |
Auto Reply Voice Select | Yes |
EMR | Yes |
RX History | Yes |
TX History | Yes |
Late Entry Receive | Yes |
Packet Loss Display | Yes |
D-STAR RX AFC | Yes |
Digital Monitor (MONI Key) | Yes |
Car Chank Display | Yes |
Характеристики
Основні | |
---|---|
Виробник | JVCKENWOOD |
Країна виробник | Малайзія |
Тип | Радіостанція портативна |
Інтерфейс | Бездротовий |
Стандарт | AM, FM, PMR 446, VHF, UHF, SSB, PMR |
Кількість каналів | 1000 |
Потужність | 5 Вт |
Шумоподавлювач | Амплітудний, Спектральний, Автоматичний |
Дисплей | Так |
Мінімальний діапазон використовуваних частот | 0.1 МГц |
Максимальний діапазон використовуваних частот | 524 МГц |
Регулировка громкости | Регулюється |
Матеріал корпусу | ABS-пластик |
Колір | Чорний |
Специфікація
Інформація для замовлення
- Ціна: 55 328 ₴
